A liquid-cooled commercial and grid-scale battery energy storage system. 100 kW continuous, 261 kWh usable, SafeBatt LFP chemistry and aerosol fire suppression — built to run hard and scale from a single cabinet to multi-megawatt installations.
Price on application. Every system is engineered to your site, so pricing is confirmed on a tailored quote. Request a quote →
Specifications
| SafeBatt Grid 100/261 — Specifications | |
| Continuous power | 100 kW |
| Usable energy | 261 kWh |
| Battery chemistry | SafeBatt LFP (lithium iron phosphate), 3.2 V / 314 Ah cells |
| System voltage | 648–936 V DC (nominal 832 V) |
| Charge / discharge rate | ≤ 0.5C |
| Round-trip efficiency | ≥ 94% |
| Cooling | Liquid cooling (integrated thermal management) |
| Fire suppression | Aerosol — pack level and cluster level |
| Cycle life | > 6,000 cycles (25°C, 0.5C, 80% DOD) |
| Monitoring / comms | CAN, RS485, Modbus-TCP, LAN; MQTT and IEC 61850 for SCADA |
| Grid connection | 380 V AC, integrated 100 kW inverter |
| Protection | IP54, C3 corrosion grade |
| Operating temperature | Discharge −20 to 55°C · Charge 0 to 55°C |
| Dimensions / weight | 1000 × 1350 × 2300 mm · 2.5 t |
| Certification | GB/T 36276-2023, UN38.3, IEC 62619 |
| Scalability | Parallel multiple cabinets into the megawatts |
Built for serious sites
- Liquid-cooled for stable performance and long life in demanding duty cycles
- Three-level BMS with full monitoring, alarms and event logging
- Grid, backup and generator-compatible; utility SCADA integration (IEC 61850)
- Modular — start at one cabinet, scale to multi-megawatt installations
Designed and assembled in Australia with the SafeBatt LFP platform at the core. Related: Grid Augmentation · Grid-Scale Storage.
