This unit is ready to go with billing bypassed, 50A 3 Phase AC connector, Trolley and all required protections. Perfect companion for any business using EVs regularly or breakdown services.

Rated Power :20KW
Output Power: 1PLUG (DC*1)
(CCS1 or CCS2: 150Vdc–1000Vdc, 0~66.7A)
Communication: OCPP 1.6J
Network: Ethernet/4G
Application: Indoor/Outdoor
Working Temperature: -30℃~+55℃
Protection Level: IP55
Cooling: Automatic forced-air cooling
Standards: IEC61851-1, IEC61851-23
Enclosure: Steel
Dimension: 450*250*850mm(L*W*T)
Net Weight: 65kG
Installation: Wall-Mounted
* 9.1inch LCD TouchS creen
* Emergency Stop Button
* LED indicator
* 5m cable length
* 2 RFID Cards

Lead time 3-4weeks for delivery

All Current options from 10A-50A available.

Schneider RCBO that fits directly to chassis.
10A - A9DC1910 - A9 iC60H3 3P+Ns C Curve 30mA A RCBO
16A - A9DC1916 - A9 iC60H3 3P+Ns C Curve 30mA A RCBO
20A - A9DC1920 - A9 iC60H3 3P+Ns C Curve 30mA A RCBO
25A - A9DC1925 - A9 iC60H3 3P+Ns C Curve 30mA A RCBO
32A - A9DC1932 - A9 iC60H3 3P+Ns C Curve 30mA A RCBO
40A - A9DC1940 - A9 iC60H3 3P+Ns C Curve 30mA A RCBO
50A - A9DC19150- A9 iC60H3 3P+Ns C Curve 30mA A RCBO
